Wi-Fi 6 Outdoor Omnidirectional Access Point AX1800 802.11ax Dual-bands 1.8 Gbps

57MM-AP06 Ruijie No. RG-RAP6262(G)

$323.00
RRP $435.00
SAVE $112.00 (26%)
In Stock


Calculate Shipping



Free pick-up from store - $0.00
Free pickup from Gordon Macdonald's Wollongong Store. 93 Auburn Street, Wollongong NSW 2500. Open 06.30-16.30 Mon-Fri, and 07.30-11.00 Sat.

The 57MM-AP06 Wi-Fi 6 outdoor omnidirectional access point is a high-power dual-band access point. Designed for use in caravan parks, town centres, villas, parks, scenic spots, and other suitable outdoor applications to provide high-speed Wi-Fi to multiple end users. The AP06 can simultaneously work in the 2.4 GHz and 5 GHz frequency bands and supports dual-band dual-stream MU-MIMO.

Features and Benefits

  • Outdoor high-range WiFi-6 (802.11ax) supporting speeds up to 1775 Mbps (Concurrent, high-speed wireless access of 574Mbps at 2.4GHz and 1201Mbps at 5Ghz)
  • Compliant with 802.11a/b/g/n/ac/ax Wi-Fi protocols
  • Free lifetime Ruijie Cloud management: Remote fault alarm, one-click optimizing and maintenance on the Ruijie Cloud app.
  • Featuring maximum Wi-Fi coverage range of 100m for 2.4GHz and 300m for 5GHz
  • Perfect for use in outdoor settings like caravan parks, villas, town centres, sports grounds and parks etc
  • Up to 256 simultaneous users per access point

(57MM-AP06)

Specifications

Basic Feature
Wi-Fi Standards Wi-Fi6 (IEEE 802.11ax), Wi-Fi5 (IEEE 802.11ac Wave2), Wi-Fi4(IEEE 802.11n)
RF Design 2.4 GHz, 2×2, MU-MIMO
5 GHz, 2×2, MU-MIMO
Max. Wi-Fi Speed 2.4 GHz: 574 Mbps
5 GHz: 1201 Mbps
Antenna 4
Antenna Type Built-In Omnidirectional
Antenna Gain 2.4 GHz: 3 dBi ,5 GHz: 5 dBi
Transmit Power EIRP
≤ 26 dBm(2.4GHz), ≤ 25 dBm( 5GHz ), country-specific restrictions apply, Myamar/Thailand: 2400~2483.5MHz ≤ 20dBm, 5150~5350MHz ≤ 23dBm, 5470~5850MHz ≤ 25dBm
Fixed Ports 2×10/100/1000 Base-T
Max. Clients 256, 64(2.4GHz) or 256(Total)
Recommended Clients 100, 11AX Terminal: 16(2.4GHz) + 84(5GHz), 11AC Terminal: 16(2.4GHz)+64(5GHz)
Max. SSIDs 8
Weight 1.05kg (excluding mounting kits)
Service Ports 110/100/l000M/2.SG Base-T Ethernet ports, supports PoE; 1 10/100/l000M Base-T ,Ethernet ports
Management Port NA
LED Indicator Single indicator (green light)
Power Supply Local power supply, DC 12V/1.5A (Note: The power adapter is sold as an optional accessory), 802.3at PoE (Warning:802.3af or non-standard POE adapter may cause unknown issues. Please use Ruijie POE+ switch or 802.3at POE adapter as power supplier)
Software Feature
WLAN Basic Features
SSID Hiding Support
Power Adjustment Support
Roaming Layer 2 roaming, Layer 3 roaming
OFDMA Support
Target wake time (TWT)* Support
WMM Support
Radar Signal Detection and Frequency Hopping Support
WLAN Security
Security Mode WPA-PSK, WPA2-PSK, WPA/WPA2-PSK;
Blacklist and Whitelist Support
Enhanced User Experience
Wi-Fi Optimization Support
Automatic RF adjustment via the platform Support
User Isolation Layer 2 user isolation
STA limit Support
Removing Low-RSSI STAs Support
Configuring STAs' RSSI Threshold Support
Average Speed Threshold Support
Adjusting Sending Rate of Beacon and Probe Response Support
Syslog Recording Why Users Lose Connection Support
Auto Channel and Power Adjustment on Cloud Support
RSSI Threshold for STA Access Support
Quick channel adjustment (auto channel selection) Support
Networks
Network Access Mode DHCP Client
VLAN Support
System
Cloud Management Support
App Management Support
App Upgrade Layer 2 user isolation
App Restart Support
Scheduled Restart Support
Local Upgrade Support
Online Upgrade Support
Factory Reset Support
WLAN Features
Frequency Bandwidth 2.4 GHz: 20/40 MHz, 5 GHz: 20/40/80 MHz
Recommended Wi-Fi Coverage Radius 2.4G 50m, 5G 150m
Max. Wi-Fi Coverage Radius 2.4G 100m, 5G 300m
Operation Frequency Bands 802.11b/g/n/ax: 2.400 GHz to 2.483 GHz, 802.11a/n/ac: 5.150 GHz to 5.350 GHz, 802.11a/n/ac/ax: 5.470 to 5.725 GHz , 5.725 to, 5.850 GHz, country-specific restrictions apply
Physical
LED Indicator 3× system LED indicator
Buttons 1×Reset button
Dimensions (W x D x H) 200mm × 220mm × 166mm(Without Mounting
Bracket)
Weight 1.2kg(Without Mounting Bracket)
Environmental
Operating Temperature -30°C to 65°C
Storage Temperature -40°C to 85°C
Operating Humidity 0% to 100% (Noncondensing)
Storage Humidity 0% to 100% (Noncondensing)
IP(Ingress Protection) IP68
Port Surge 4 kV
MTBF >250000H
SKU 57MM-AP06
Shipping Weight 1.5000kg
Shipping Width 0.250m
Shipping Height 0.200m
Shipping Length 0.250m
Shipping Cubic 0.012500000m3
